(10) Gigabit RJ45 routing ports

24V PoE support on RJ45 ports

Ports 0-7 can be configured for line-rate Layer 2 switching

(2) Gigabit SFP ports

3.4 million packets per second for 64-byte packets

6.8 Gbps for packets 1518 bytes or larger in size

Silent, fanless operation

Compact, durable metal caseDimensions: 268.1 x 136.5 x 31.1 mm (10.55 x 5.37 x 1.22″)

Weight: 700 g (1.54 lb)
Max. Power Consumption: 20W (Excludes PoE Output)
Power Method: External AC/DC Power Adapter, 12W (24V, 2.5A) (Included)
Power Supply: External AC/DC Adapter
Supported Voltage Range: 9 – 30VDC
Button: Reset
LEDs:
– Data Ports: Speed/Link/Activity, PoE
– SFP Data Port: Link/Activity
Networking Interfaces:
– Management: (1) RJ45 Serial Port, (10) Ethernet Ports (Default Port 0)
– Networking: (10) 10/100/1000 RJ45 Ports with PoE., (2) 1 Gbps SFP Ports
Layer 3 Forwarding Performance:
– Packet Size 64 Bytes: 3,400,000 pps
– Packet Size 1518 Bytes or Larger: 6.8 Gbps (Line Rate)
Processor: 4-Core 1 GHz, MIPS64
System Memory: 1 GB DDR3 RAM
On-Board Flash Storage: 4 GB eMMC, 8 MB SPI NOR
Mounting: Wall, Rack ( ER-RMKIT)
Operating Temperature: -10 to 40 C (14 to 104 F)
Operating Humidity: 10 – 90% Noncondensing
Certifications: CE, FCC, IC
